Walk in Chamber Temperature Aging Room

5% R.H low humdity walk in temperature humidity test chamber room

A walk-in Temperature, Humidity Climatic Stability Test Chamber is used to test various types of materials for their tolerances of heat, cold, dry, and humidity. It is applied for quality inspection for all types of big test samples, such as electronic products, electric appliances, and products from communication, instrument, automobile, plastic, metal, food, chemical, Building materials, medical, and aerospace industries.

We provide two primary types of walk-in chamber designs:

1. Modular walk-in chambers utilize foam panels that are connected together to form rooms of various sizes.

2 . Welded (Solid) walk-in chambers are fully welded chambers that can withstand high temperature and high humidity, along with fast temperature change rates.


Inquire Now
Description

5% R.H. low humdity walk-in temperature humidity test chamber room


• Protection (phase protection, overheat, overcurrent etc)

• Water Tank with level detector

• Adjustable Shelf

• With RS-485/232 output to computer

• Window Software

• Remote fault notification(optional)

• With Viewing Window


Application:

Temperature Humidity Controlled Stability Chambers are used to test various types of materials for their tolerances to heat, cold, dry, and humidity. It is applied for quality inspection for all Types of big test samples, Such as electronic products, electric appliances, and products from communication, instrument, Automobile, plastic, metal, food, chemical, building materials, medical, and aerospace Industries.


5% R.H low humdity walk in temperature humidity test chamber room


5% R.H low humdity walk in temperature humidity test chamber room



Technical Parameters
 Model  THR-volume (low-temperature options: A~F)
 Inner Dimensions(cm)  Customers designated the space size and design
 Temperature Range  Low Temperature(A:25degree C   B:0degree C   C:-20degree C  D:-40degree C  E:-60degree C   F:-70degree C )
High Temperature 80 degree C  (80degree C  ~150degree C  is optional)
 Humidity Range  20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is a special optional condition, need dehumidifier)
Indication Resolution/
Distribution Uniformity of
Temperature & Humidity
 0.1degree C ; 0.1% R.H/±2.5degree C ; ±3.5% R.H.
 Control Accuracy of
Temperature and Humidity
 ±0.5degree C ; ±2.5% R.H.
 Temperature Rising/
Falling Velocity
 The temperature is rising approximately.  0.1~3.0°C/min; The The
temperature is falling approximately. 0.3~1.0°C/min;
 ( The Falling Velocity Min.1.0°C /min is a optional)
 Cooling System  Water cooled
 Protection Devices Fuse-free switch, overloading protection switch  for compressor, high and low voltage coolant protection switch, over-humidity & over-temperature protection switch, fuses,  fault warning system, water short storage warning protection
 Optional Accessories  Slope for cart, Recorder, Water Purifier, Dehumidifier
 Compressor  French Tecumseh Brand, Germany Bizer Brand
 Power  AC 380 V(±10%),50/60HZ ,3 phase  5 Lines



Characteristics

1. New design temperature humidity climate test chamber walk-in test chamber Evaporator no frosting under long-term Low temperature and low humidity running.

2. The automatic control system refrigerant demand saves electricity above 30%

3. High heat load tested samples test environment

4. Realize a 95°C 95% high temperature and high humidity environment.

5.10% 20 °C ultra-low temperature range control ability

6. Multi-language selection: Chinese, English, Russian, Korean, Japanese, and German multilingual language switching.
