Long history (more than 28-year manufacturer)
CE certificate
High quality with reasonable price
standard export plywood case
fast delivery date
Application:
Water Cooled Xenon Lamp Weather Resistance Test Chamber is a comprehensive climate testing machine, it can do climatic aging test, and also can do fading acceleration test under color effect or color changed. The test range including: Dying and finishing, printing, leather, plastic, plyglass, painting, textile, printing ink, rubber and also the industry relative color. Light fastness and fade grade can be known in short time. Those materials exposed at simulated sunlight to evaluated the material's light fastness performance. To simulate and strengthen the test according to light energy, temperature, rain fall or condensation, humidity, . Etc these main climate factors. Adopt simulated sunlight spectrum's Xenon arc light to create destructive waves under different environment. It can be used for choosing new materials, improving existing materials, or assessment of durability change after material composed.
| technical parameters: |
| Model | XL-1000 |
| Internal Dimension W*H*D (mm) | 1000*1000*1000 |
| External Dimension W*H*D (mm) | 1550*2150*1550 |
| Tube Using Life (H) | 1500 |
| Tube Power | 1KW/6KW |
| Illumination Intensity | Full spectrum
1200±200w/m2 |
| Lighting Filter Type | Quartz |
| Quartz |
| Simulated Test Status | Test samples: Explore under outer space |
| Cooling System | Water cooled or wind cooled |
| Temperature Control Range of the Test Cabinet | Black panel temperature : BPT 40~120 degree (±3 degree) |
| Black standard temperature:BST 38~120 degree (±3 degree) |
| Humidity Control Range of the Test Cabinet | Humidity when lighting: 20%R.H.~75%R.H. (± 5%R.H.) |
| Humidity when dark: 60%R.H.~95%R.H. (± 5%R.H.) |
| Rotating Speed of the Samples Holder (RPM) | 1~5 adjustable |
| Diameter of Sample Shelf(mm) | 500±50 |
| Sunlight Exposure Cycle | 0.01~999 hours 59mins |
| Raining Period / Time | Raining Period:1~240mins,discontinuous-type, adjustable |
| Raining Time:1~9999mins, adjustable, water spray pressure 70~130Kpa |
| Spray water flow(L/min) | 1~2.4 |
| Explore Area(cm2) | 7500 |
| Power | AC 380 V(±10%),50/60HZ ,3 5 Lines
|
Xenon lamp test chamber features:
1. Advanced design technology and concept.
2. Excellent technology of producing and outstanding system of quality management.
3. Xenon lamp tester can be the most realistic simulated solar spectrum, including ultraviolet,
Visible and infrared.
4. Be tested in the range of the full spectrum, necessary for most textile sun and color fastness test.
5. To determine the color fastness and aging to sunlight, weather resistance, etc.
Warranty: One year free warranty for whole set machine, lifelong time maintainance.
After-sale service: Feedback within 2 hours after get the call.
Service: OEM service, Design service, Buyer lable service.
Customers Visit ASLI
ASLi main test equipments:
Environmental chambers, temperature (humidity) chamber, Thermal shock chamber, PCT /Hast chamber (Highly accelerated stress test chamber), ESS chamber, Walk in stability chamber, Vacuum oven, Electrodynamic vibration shaker, mechanical shock tester, environmental combined vibration chamber, etc
Welcome our new and regular customers visit our factory, and any inquiries about Water Cooled Xenon Lamp Weather Resistance Test Chamber, please feel free to contact us for quotation !
