| Model | TH-48 (A~F) | TH-80(A~F) | TH-150(A~F) | TH-225(A~F) | TH-408(A~F) |
|
Internal Dimension
W*H*D (mm) | 400*400*300 | 400*500*400 | 500*600*500 | 600*750*500 | 600*850*800 |
|
Internal Dimension
W*H*D (mm) | 1000*1400*1000 | 1000*1650*1000 | 1050*1750*1050 | 1200*1900*1150 | 1200*1950*1350 |
|
| Temperature Range | Low Temperature ( A: 25degres Celsius B:0degres Celsius C:-20degres CelsiusD:-40degres Celsius E:-60degres Celsius F:-70degres Celsius)
High Temperature: 100degres Celsius (150degres Celsius is optional) |
| Humidity Range | 20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is optional , need Dehumidifier) |
Indication relolution/
Distribution uniformity
of temperature and humidity | 0.1degres Celsius; 0.1% R.H/±2.0degres Celsius; ±3.0% R.H. |
Control Accuracy of
Temperature and Humidity | ±0.5degres Celsius; ±2.5% R.H. |
Temperature Rising/
Falling Velocity | Temperature rising approx. 0.1~3.0degres Celsius/min ;
temperature falling approx. 0.3~1.0degres Celsius/min;
( Falling Min.1.5degres Celsius/min is optional) |
| Inner and Outer Material | Interior material is SUS 304# stainless steel, exterior is stainless steel or SEE
cold-rolled steel with paint coated. |
| Insulation Material | Resistant to high temperature, high density, formate chlorine, ethyl acetum foam
insulation materials |
| Cooling System | Wind cooling or water cooling, (single segment compressor-40degres Celsius,
double segment compressor -70degres Celsius) |
| Protection Devices | Fuse-free switch, overloading protection switch for compressor, high and low
voltage coolant protection switch, over-humidity and over-temperature protection
switch, fuses, fault warning system, water short storage warning protection |
| Optional Accessories | Inner door with operation hole , Recorder, Water Purifier, Dehumidifier |
| Compressor | French Tecumseh Brand, Germany Bizer Brand |
| Power | AC220V 1Ph 3 lines, 50/60HZ , AC380V 3Ph 5 lines , 50/60HZ |
| Approx. Weight (Kg) | 150 | 180 | 250 | 320 |
|
|
